SOLID COPPER
Cat6 cable is used for connecting a computer to another device like a hub, router or switch in order to allow the sharing of files across a network or for accessing the Internet. It can also be used for connecting computers to other devices together such as printers or scanners, or for incoming and outgoing LAN connections on patch panels. With the potential for higher speeds and less crosstalk, Cat6 cable currently dominates home and enterprise networks as the cable of choice.
72 V
-10°C to +60°C
Dielectric strength – 1000 V RMS
Insulation Resistance – 100 MΩ
Conductor Resistance – Max. 9.38 Ω/km
Conductor Resistance Unbalance – Max 5%
Mutual Capacitance – Max. 5.6 nF/100m
Capacitance Earth Unbalance – Max 330 pF/100m
Propagation Delay – < 538 ns/100 Mtr
Delay Skew – 45 ns/100 Mtr
Current Rating – Max 1.5 A
1 – 2: White-Orange Strip and Orange
3 – 6: White-Green Strip and Green
4 – 5: White-Blue Strip and Blue
7 – 8: White-Brown Strip and Brown
Fixed Installation | 12 x overall diameter
